G5W11-WZ100A06-W3U
g5w11-wz100a06-w3u-01
g5w11-wz100a06-w3u-01
g5w11-wz100a06-w3u-02

G5W11-WZ100A06-W3U

  • Origin: Guangdong, China (Mainland)

  • Brand Name:Unionwell

  • Model: G5W11-EZ050A02-W2U

  • Terminal type: quick-connect terminal

  • Contact form: single pole double throw

  • Operating handle type: standard straight handle

  • Safety certification: All products have obtained major global safety certifications

  • Company quality assurance system:ISO9001andIATF16949and ISO14001

  • Applications: Household appliances, electronic equipment, automation equipment, automotive electronics, agricultural machinery, office equipment, etc.


Contact Us

Features

  • Waterproof and dustproof (IP67）

  • Compact structure, small movement stroke, high sensitivity

  • Global safety certification

  • Long life, high precision and high reliability

  • Various handles available

  • Widely used in automotive electronics, home appliances and industrial control, etc.

  • MaximumENEC / ULCertified current up to10A


Characteristics parameters

Rating

W1

ENEC: 0.1A 48VDC, 0.1A 125/250VAC, 40T85, 5E4, u UL: 0.1A 48VDC, 0.1A 125/250VAC, T85

W2

ENEC: 5A 125/250VAC, 5A, 30VDC, 40T85, 5E4, u UL: 5A 125/250VAC, T85

W3

ENEC:10(2)A 125/250VAC, 0.5A 125VDC, 0.25A 250VDC,40T85,u,2E4 UL:10.1A 1/10HP 125/250VAC,0.5A 125VDC, 0.25A 250VDC, T85

Operating frequency

electric

10~30 times/min

mechanical

60 times/min

Contact resistance

Terminal type

50mΩMax

Lead wire type

100mΩ Max(Depends on the length of the wire)

Insulation resistance

at 500VDC,100MΩ Min.

Dielectric strength

Between terminals of the same level

AC 1000V 50-60Hz 1min

Terminal housing

AC 1500V 50-60Hz 1min

Storage temperature

-40°C~+85°C

Storage humidity


85%RH Max

Protective structure

Terminal type

IEC IP67(Terminal not included)

Lead wire type

IEC IP67

Protection level against electric shock

Class I

PTI

250

life

electric

2E4~10E4 cycles(depends on P/NS)

mechanical

over 1000,000cycles(60cycles/min)

Unit weight

Approx.7g(Terminal type, without handle)
