Push Button Electrical Switches PCB Terminals G9
Push Button Electrical Switches PCB Terminals G9
Push Button Electrical Switches PCB Terminals G9
Push Button Electrical Switches PCB Terminals G9

Push Button Electrical Switches PCB Terminals G9

  • Place of Origin: Guangdong, China (Mainland)

  • Model Number: G905-200P01D1

  • Terminal Type: Straight PCB Terminals

Descriptions of Push Button Electrical Switches PCB Terminals G9

A miniature snap-action switch, and also often called a micro switch, is actually a power button that is activated by very little bodily pressure with using a tipping-point system, often referred to as an "over-center" system.

Switching over takes place dependably at certain and repeatable positions of the actuator, which is actually certainly not necessarily accurate of other mechanisms. They are actually omnipresent due to their low cost yet higher sturdiness, higher than 1 million patterns, and also up to 10 million cycles for sturdy designs. This longevity is an organic consequence of the layout.


Quick Details of Push Button Electrical Switches PCB Terminals G9

  • Dust and Water Proof(IP67)Design

  • Small Compact Size

  • Long Life, High Reliability

  • Variety of Terminals and Levers

  • Wide Range Operating Force


Specifications of Push Button Electrical Switches PCB Terminals G9

Rating

p1

0.1A 125/250VAC 48VDC/GoldPlated Contact Optional

05

UL: 5A 125/250VAC

ENEC: 6A 125/250 1E4; 3A 125/250VAC 30VDC 5E4 µ25T120

Operating Frequency

Electrical

10~30cycles/minute

Mechanical

120cycles/minute

Contact Resistance (Initiative)

100mΩ Max/It depends on the wire length for the type with wire

Insulation Resistance (at 500VDC)

100mΩ Min

Dielectric Strength

AC1,000V RMS (50~60Hz)

Storage Temperature

-25°C~+120°C

Storage Humidity

85%RH Max

Service Life

Electrical

10,000cycles/Depend on part No.

Mechanical

500,000cycles
