Name: Sealed Mini Micro Switch Dust G9
Brand: Guangzhou Unionwell Sensing & Control Technology Co., Ltd.

Sealed Mini Micro Switch Dust G9

Greetech is a factory focusing on automotive switch design and manufacturing.
We showcase G3 series, G5W series and G9 series micro switches or snap action switch for automotive applications.
These switches can be customized base on special requirements if the annual quantity reaches our requirements and most of them are designed as waterproof switches.

RM1311, Renfeng Building, No. 490, Tianhe Road, Tianhe District, Guangzhou, Guangdong, China, 510630.

Place of Origin	Guangdong, China (Mainland)
Brand Name	Unionwell
Model Number	G905-200E07W1N-U
Electrical Rating	ENEC/CQC: 6A 125/250VAC 1E4 μ 3A125/250VAC 30VDC 5E4 UL/CUL: 5A 125/250VAC
Operation Force	200gf Max
Terminal Style	Wires leads to bottom(500mm)
Lever Type	Small simulated roller lever 19mm
Construction	Water tight- IP67 With lead wires
Circuit Code	SPDT

Sealed Mini Micro Switch Dust G9

Descriptions of Sealed Mini Micro Switch Dust G9
